Outdoor Industrial Water Resistant Touch Screen Monitor 1500 Nits 32 Inch
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Pure LCD Panel | 1500cd/m² | With Touch Monitor | 1250cd/m² |
|---|---|---|---|
| Video Input | VGA/DVI/HDMI | Active Area | 700.6*395.1 (mm) |
| Contrast Ratio (Typ.) | 4000:1 | Display Type | 16:9 Ratio 32" TFT-LCD |
| Product Name | High Brightness Touch Monitor | Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) 89°/89° Vertical(up/down) 89°/89° |
| Frequency (H/V) | 30～80KHz / 60～75Hz | Series | OT |
| Leadtime | 7-15 Days | MTBF | ≥ 30,000 Hours |
| Warranty | 1 Year | Sample | On Stock |
| High Light | Water Resistant Touch Screen Monitor 1500Nits,Water Resistant Touch Screen Monitor 32Inch,Outdoor industrial touchscreen monitor | ||
Product Description
Outdoor Industrial High Brightness 1500nits 32 Inch Waterproof PCAP Touch Screen Monitor
High Brightness Touch Monitor Main Features
1. Support embedded,wall-mounted,rack-mounted,desktop,VESA support.
2. Aluminum alloy shell,good mechanical properties,better performance of heat dissipation.
3. LED backlight screen,highlight picture,perfect color.
4. Support Resistive touch, SAW touch , IR touch, Capacitive touch.
5. CCC, UL, FCC, CE, CB, RoHS certificate.
6. Complete machine triple protection:explosion-proof, flameproof, moisture-proof.
High Brightness Touch Monitor Specifications
Complete Machine | ||
Model No. | KOT-0320U-CA4PH (P/N:KOT-320P-013) | |
Series | OT | |
Display Type | 16:9 Ratio 32" TFT-LCD | |
Active Area | 700.6*395.1 (mm) | |
Monitor Dimensions (W*H*D) | 769*463.5*58.6 (mm) | |
Suggested Resolution | 1920x1080 @ 60Hz | |
Support Colors | 16.7M | |
Brightness (Typ.) | Pure LCD Panel | 1500cd/m² |
With Touch Monitor | 1250cd/m² | |
Response Time (Typ.) | 6ms | |
Viewing Angle(Typ.at CR＞10)） | Horizontal(left/right) | 89°/89° |
Vertical(up/down) | 89°/89° | |
Contrast Ratio (Typ.) | 4000:1 | |
Video Input | VGA/DVI/HDMI | |
Frequency (H/V) | 30～80KHz / 60～75Hz | |
Power Supply | Type: External brick Display voltage: DC 24V/ 5A | |
Environment | Operating Temp. | -15～50°C |
Operating RH | 20%～80% | |
Storage Temp. | -20～60°C | |
Storage RH | 10%～90% | |
LED Back Light Life (Typ.) | 30,000 Hours | |
Mount Interface | 1.VESA 400*400 mm 2.Mount bracket, horizontal or vertical mount | |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
CCC, UL, FCC, CE, CB, RoHS | ||
Regular Warranty | 1 year | |
Touch Screen | |
Touch Type | 32" Capacitive touch screens |
Touch input | USB |
Response Time | ≤10ms |
Hardness | ≥6H |
Light Transmittance | ≥83% |
Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
Touch Test | ≥50,000,000 times |
Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
Applications
1. Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums,convention centers, ticket agencies, HR market, lottery centers;
2. Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
3. Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
4. Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.
FAQ
1. What's your MOQ?
Our minimum order quantity is 1pc only.
2. What is your warranty period?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
3. Can you produce the product according to the customer's requirements?
Sure, with 40+ Professional R&D engineers, OEM and ODM are offered.
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Credit card, and Alipay.(L/C can be negotiable.)
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
6. Do you give any discount?
We will do utmost to support you with the competitive price, also good service will be offered.
